230V RW3400 Roofer Automatic Plastic Welder with 40mm Overlap Nozzle

RW3400 roofer is a kind of powerful automatic plastic welder for rooftop welding and also for thicker TPO overlap welding.
Item Code: JK-HW-RW3400
Price:
    Please select the information you wantX
Shipping Cost:
to
Estimated Delivery Time:
Please select the country you want to ship from
+
-
set
  • Description
Specifications
Description:
RW3400 roofer is a kind of powerful automatic plastic welder for rooftop welding and also for thicker TPO overlap welding.
  • Extra wide 40 mm welding nozzle fulfills international standards.
  • Heavy weight direct above the contact roller results in high quality weld seam.
  • Powerful 3400W hot air blower to achieve the desired temperature and air volume.
  • Integrated laser beam for easy machine guidance.
  • WELDY hot air gun and welding thickness is up to 2mm.
  • Free adjustable speed up to 7.5m/min.
  • Made for TPO and PVC materials.
  • Automatic driving and welding start.
  • Guide bar and lifting device for easy handling.
  • Free variable welding temperature.


Specification:
Voltage: 220V±10%(single phase)
Power: 3400W
Temperature: 50°C-600°C
Speed: 1-7.5m/min
Welding Seam Width: 40mm
Weldable Materials: PVC, TPO, ECB, EPDM, CSPE
Dimension: 500 x 365 x 270mm
Net Weight: 15kg

Packing Details:
Packing Size: 580 x 460 x 370mm
Gross Weight: 25kg

Warm Tips: The plastic welder is 230V(single phase), the generator will be recommeded when using in the 120V countries.

Applications:
The RW3400 roofer is a professional welder for rooftop welding and thicker materials, like arpaulins, TPO, ECB, EPDM, CSPE, etc.
